9
major application
minor application
roughing
pre-finishing
finishing
SLOTWORX® - k90°
Size M - diam. 16 - 52 mm
This range is the all-purpose solution for square shoulder face milling and slotting. Can
be used with indexable inserts of the Slotworx®-M range up to a corner radius of 2 mm.
Modified standard bodies for the use of indexable inserts with a corner radius >= 3 mm
have additional R+ marking.
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
l
r
l
3
l
2
l
1
d
2
d
3
z
DuoPlug®
l
2
l
3
l
d
1
d
3
r
d
2
2 16 267 SG 16 10 0.8-2 38 2.5 -
M 10 15 2 A, C, D,
E, F
2 16 267 SG R+ 16 10 3|4 38 2.5 -
M 10 15 2 A, C, D,
E, F
2 20 267 SG 20 10 0.8-2 40 2.5 -
M 12 18.6 2 A, C, D,
E, F
2 20 267 SG R+ 20 10 3|4 40 2.5 -
M 12 18.6 2 A, C, D,
E, F
3 25 267 SG 25 10 0.8-2 43 2.5 -
M 16 23.5 3 A, C, D,
E, F
3 25 267 SG R+ 25 10 3|4 43 2.5 -
M 16 23.5 3 A, C, D,
E, F
