Important: the scope of delivery of each
COOLCAP
®
cooling arbor includes one cap each. When ordering, please
always state whether you want a cap for air/MMS or a cap for emulsion/cooling water. Additional caps can be orde-
red separately. Always tighten and loosen caps only with an application tool or a box wrench!
SK 40 DIN 69871AD
for Weldon shank | CoolCap®
• Steep taper shanks according to DIN 69 871 AD, maximum precision
• fine balanced to G 6.3 gmm at 18,000 rpm
• with internal coolant supply and bore hole for the coolant supply tube
• effective direct cooling for solid carbide end mills because of a ring-shaped
cooling jet
• increased process reliability when using milling cutter bodies with indexable
inserts in connection with extensions by removing the chips from the cutting area
for Weldon shank |
CoolCap®
Catalogue no.
Form/DIN
Accessories
Features
d
1
l
3
A d
3
d
4
d
2
l
2
l
1
d
2
A
l
3
d
3
d
1
d
4
for diam. 10
50 10 750 SR1 W diam.
10
50 69.1 22.5 30.4 SK 40 DIN 69871
AD
-
-
C, D, E, H,
K, L
for diam. 12
60 12 750 SR1 W diam.
12
60 79.1 26.5 36 SK 40 DIN 69871
AD
-
-
A, D, F, I,
K, L
for diam. 16
60 16 750 SR1 W diam.
16
60 79.1 31.5 41 SK 40 DIN 69871
AD
-
-
B, D, G, J,
K, L
Accessories
M12X10
screw
A > Page 12
M14X12
screw
B > Page 12
M10X10
screw for reduction
sleeve
C > Page 12
KBSK40-69872A
retention knob with
through hole
D > Page 12
SR1 S10 SW22
COOLCAP®-Screw-
On Cap for shrinking
Ø 10, E > Page 12
SR1 S12 SW27
COOLCAP®-Screw-On
Cap for shrinking Ø 12
F > Page 12
SR1 S16 SW32
COOLCAP®-Screw-On
Cap for shrinking Ø 16
G > Page 12
SR1 A10 SW22
COOLCAP®-Screw-On
Cap for shrinking Ø 10
H > Page 12
SR1 A12 SW27
COOLCAP®-Screw-On
Cap for shrinking Ø 12
I > Page 12
SR1 A16 SW32
COOLCAP®-Screw-
On Cap for shrinking
Ø 16, J > Page 12
SR1 ZSW 001
COOLCAP®-applying
tool
K > Page 13
DMS 3/8 8-60 NM
torque wrench 3/8“
L > Page 13
