3
coolcap
®
excellent attributes at a glance
uu
The selective supply reduces the compressed air consumption
while increasing effectiveness
uu
When necessary, caps can be simply, quickly and cost-effectively
replaced without influencing the usability of the arbors
uu
Sealing without sensitive gaskets or other sealing materials
uu
Ring-shaped cooling jet for ideal cooling performance
and chip flushing
uu
Volume flow and discharge velocity are perfectly matched to
the different mill diameters
COOLCAP
®
operating principle
uu
The annular gap reduces the danger of blockage due to particles
uu
Simple installation with the application tool
coolcap
®
in action: uniform,
ring-shaped cooling jet
Coolant supply
Fine-pitch thread
Volume-flow
reservoir
Coolant control
On top of that, with its extre-
mely small discharge aperture,
COOLCAP
®
for air-cooling
reduces the use of expensive
compressed air.
Replaceable
COOLCAP
®
-caps, perfectly matched to
the various cooling media, are a decisive factor for
achieving excellent milling performance.
COOLCAP
®
for emulsions
guarantee the highest possible
plus a targeted volume flow,
which effectively removes
chips from the cutting zone
even with large tools.
uu
Through the subsequent installation of the caps, it cannot impair
the shrinking process
uu
Longer lifetime of the milling tool
uu
The low mass of the cap of less than 30 g does not influence the
balance quality of the arbor (G 6.3 at 18,000 / 12,000 rpm)
uu
Various
coolcap
®
, structurally designed for the various
cooling media of air/MLQ or emulsion
uu
Increased process reliability when using milling cutter bodies with
indexable inserts in connection with extensions by removing the chips
from the cutting area
