12 mm
16 mm
20 mm
25 mm
20, 40, 60, 80 25, 50, 75, 100,
125, 150
25, 50, 75, 100,
125, 150, 175
25, 50, 75, 100, 125,
150, 175, 200
M 7
M 10
M 12
M 16
6 mm
8 mm
10 mm
35, 45, 50
45, 50
50
M 10, M 12, M 16
M 12, M 16
M16
Duoplug
®
- combination clamping system
The perfection of the shrink connection
I
n this internationally unique combination clamping system
that is patented for Pokolm, the heated DUOPLUG
®
milling cutter body or shrinking adapter is screwed onto the
special thread counterpart. The subsequent cooling off or
shrinking process of the tool creates the perfect connection.
DUOPLUG
®
guarantees the best concentricity and rigidity
- even with long shanks and roughing processes in the high-
speed range.
The absolutely backlash-free and centred fittings also achieve
incomparable precision in the roughing area. Naturally, this
is connected to the retention forces necessary for this appli-
cation area.
And that lets you easily achieve milling performance at the
highest level.
DUOPLUG
®
shrinking adapters
Shrinking adapters also put the extreme DUOPLUG
®
connection precision into the HSC area.
They create the ideal supplement for processing deep cavities.
With POKOLM solid carbide adapters, the required process reliability is always guaranteed
even during unmanned operation.
Diameter:
Lengths (mm):
Duoplug
®
Thread:
Diameter:
Lengths (mm):
Duoplug
®
Thread:
Solid carbide adapters for the DUOPLUG
®
combination clamping system
DUOPLUG
®
- combination clamping system
11
