Induction shrinking station TSI11000WK -
High-performance, safe, easy-to-use device
Scope of delivery
Induction shrinking station TSI11000WK
Adapter, water cooled
The scope of delivery includes an adapter.
Please state the desired item no. in your order.
(See selection on page 6)
Ferrite discs,
complete set including 4 units
3.0 - 5.9 mm; 6.0 - 12 mm; 12.1 - 22 mm; 22.1 - 32 mm
Cooling emulsion
, 1l canister
Clamping ring
, 1 unit
Protective gloves
, 1 pair
Transport box
uu
High-performance, easy-to-use device
uu
Even shorter shrinking times
uu
Targeted heating
uu
Minimised danger of burns
uu
Shortened setup times
uu
Simple operation
uu
Integrated water cooling
uu
Perfect for
DuoPlug
®
Advantages at a glance
T
he TSI11000WK induction shrinking station provides the
user an 11 kW powerful, easy-to-use device that boasts
the latest type of construction. It has high capacity design
margins and a great number of innovative attributes.
For instance, the semi-automatic shrinking and fluid-sup-
ported cooling process is run in a single position in the unit.
A ferrite disc system prevents the tool from heating up and
facilitates problem-free clamping of FHM tools and rods as
well as heavy metal extensions - the hot spot is pushed into
the ideal area.
Equipped with automatic water cooling, the shrinking arbor
in the unit is always cooled to room temperature. Over-
heating and risk of burns along with damage to the tool
edge are made impossible. Setup times are reduced to a
minimum.
The operating concept is especially user friendly.
Comprehensive protection systems prevent damage
to the arbor or the unit on top of that.
The all-in-one solution per-
mits the shrinking and cool-
ing process in one position.
There is no contact with the
hot chuck. That excludes a
danger of burns and saves
time.
Water cooling system
Reduces tool heat-up. The
hot spot is pushed into the
ideal area. Adapting the
magnetic alternating field
increases the efficiency.
Ferrite disc changer system
induction shrinking station TSI11000WK
