Induction shrinking station TSI11000WK
Operator's controls, technical data
Operator control panel for simple
selection of permanently stored
parameters or for manual opera-
tion
Compact controller unit
Manual coil guide for strip-
curtain movement
Shrinking arbors using innova-
tive water cooling to cool off in
a flash without moving the hot
arbor
Fluid tank
On request, the induction shrinking station is also available in a version with a replaceable exchange-coil for large clamping
diameters up to 50 mm.
Technical data
Name
TSI11000WK
Output
11 kW
System voltage
400 V, 50 Hz, 16 A
Cooling
Fluid cooling
Degree of protection
IP 40
Max. machine interface
HSK100, SK50
Contour-independent cooling
Yes
Cooling time
variably
Fluid tank
22 l
Dimensions
L 800, W 560, H 950 mm
Clamping range Solid Carbide
Ø 3 - 32 mm
Coil
fixed, Ø 54 mm
Max. tool length
400 mm in the HSK63
Max. cooling length
160 mm in the HSK63
Weight
~ 88 kg incl. packaging
Induction shrinking station TSI11000WK
Operating elements
