SPINWORX®
r8 - diam. 40 - 80 mm, 7° positive rake angle
Highly efficient SPINWORX systems, also available in intermediate sizes
• wide range of uses for almost all areas of application
• effective use of cutting edge
• with specially adapted primary and secondary coolant supply
• high chip removal rate•
CAUTION! PLEASE NOTE!
For optimum results with the SPINWORX®-tooling system we recommend using internal
coolant supply air, emulsion or MQL for chip removal from the tool! Wet machining up
to max speed Vc of 140 m/min!
Milling cutter bodies
Catalogue no.
Accessories
Features
d
1
d r
l
3
l
2
l
1
d
2
d
3
z
Threaded shank end mill bodies
l
2
d
3
l
3
d
2
d
1
d
DR16-040-E16-04 40 16 8 43.5 3.8 -
M 16 29 4 B, C, D, E
Shell-type milling cutter bodies
l
2
l
3
d
1
d
3
d
d
2
DR16-052-A22-05 52 16 8 53 3.8 -
diam. 22 40 5 A, B, C,
D, E
DR16-066-A27-06 66 16 8 53 3.8 -
diam. 27 48 6 B, C, D, E
DR16-080-A27-07 80 16 8 53 3.8 -
diam. 27 60 7 B, C, D, E
Accessories
GWSTPS10ISK
hexagon socket set screw
A > Page 21
T20-2,5NM
Torque Fix® - S torque
screwdriver
B > Page 21
T20 500
Torx interchangeable bit
for Torque Vario®
C > Page 21
T20 502
Torx MagicSpring
compatible bit f. Torque
Vario®, D > Page 21
Z 00043
HTC ceramic paste WS
600 005
E > Page 21
spinworx
®
Copy milling cutters milling cutter bodies
